Standard Specification :

IEC60502                                                                                                          BS 5308-2

Other specifications are available upon request

Rated Voltage :

300/500 V

Number of pairs :

1 – 50 pairs

Cross Sectional Area :

·         Conductor    : 1.5 – 2.5 mm²

·         Drain Wire    : 0.5 mm²

Application :

Instrumentation cables are suitable for industrial control system as needed in measurement, control, signalling and data system technology.

Special Features on Request :

• Fire Resistance
• Oil Resistance
• UV Resistance
• Flame Retardant Cat. A, B, C
• Flame Retardant Non Category
• Heat Resistance
• Anti Termite
• Anti Rodent
• Low Smoke Zero Halogen
• Nylon Coated

Note :

Conductor Shape

All construction supplied in solid (re) or non compacted circular stranded (rm)

Standard Packing

Size 1.5 mm² :

       > All conductor supplied in wooden drum @ 1000 m

Size 2.5 mm² :

      > 1 – 36 pairs supplied in wooden drum @ 1000 m

     > 40- 50 pairs supplied in wooden drum on available length

Length Tolerance per drum ± 2%
